10.1 Inch 800x1280 With Ips Mipi Interface 40 Pins Tft Lcd Display
General Description:
M101MB40IG002 each pixel is divided into RED, GREEN, BLUE dots which are arranged in vertical stripe and this module can display 16.7M colors. The TFT-LCD panel used for this module is adapted for a low reflection and higher color type.
Specifications:
| Parameter | Specification | Unit | Remarks |
| Active Area | 135.36(H) x 216.576(V) | mm | |
| Number of Pixels | 800(H) x 1280(V) | pixels | |
| Pixel Pitch | 0. 1692(H)x0. 1692(V)xRGB | mm | |
| Pixel Arrangement | Pixels RGB stripe arrangement | ||
| Interface | MIPI | ||
| Display Colors | 16.7M | colors | |
| Display Mode | Normally black, Transmissive | ||
| Outline Dimension | 143 x 228.6 x 2.80 (typ.) | mm | |
| Weight | 138± 15% | gram | |
| Surface Treatment | Hard coating | ||
| Back-light | Bottom edge side , 1-LED lighting bar type | 28*LED array |
Absolute Maximum Ratings:
| Item | Symbol | Min. | Max. | Unit |
| Power Voltage | VDDI | 1.65 | 3.6 | V |
| Operating Ambient Temperature | TOP | - 10 | +50 | ℃ |
| Storage Temperature | TSTG | -20 | +60 | ℃ |
Electrical Specifications:
| Item | Symbol | Condition | Min | Typ | Max | Unit | Pins |
| Power Supply Voltage *1) | VDDI | 3.0 | 3.3 | 3.6 | V | ||
| Low-level input voltage | VIL | 0 | - | 0.3 x VDDI | V | RESX | |
| High-level input voltage | VIH | 0.7xVDDI | - | VDDI | V | RESX | |
Low-level output voltage | VOL | IOL=+ 1mA | 0 | - | 0.2 x VDDI | V | TE |
| High-level output voltage | VOH | IOH=- 1mA | 0.8xVDDI | - | VDDI | V | TE |
| Input high level leakage current | IIH | VIN=IVDDI | - | - | 1 | μA | RESX |
| Input low level leakage current | IIL | VIN=GND | - 1 | - | - | μA | RESX |
| Power supply current | IVDDI | - | 180 | 220 | mA | VDDI | |
| Sleep current | IVDDI | - | - | 125 | μA | VDDI |
Optical Specification:
| Parameter | Symb ol | Condition | Min | Typ | Max | Unit | |
View Angles | θT | CR= 10 | - | 80 | - | Degree | |
| θB | - | 80 | - | ||||
| θL | - | 80 | - | ||||
| θR | - | 80 | - | ||||
| Color Gamut | CG | 55 | 60 | - | % | ||
| Contrast Ratio | CR | θ=0° | 800 | 1000 | - | ||
| Luminance of White | Center | YW | θ=0° | 250 | 300 | - | cd/m2 |
| Luminance Uniformity | 13 Points | ΔY13 | 75 | 80 | - | ||
| White Chromaticity | Wx | θ=0° | TYP - 0.03 | 0.304 | TYP +0.03 | ||
| Wy | 0.320 | ||||||
| Response time(Rising+Falling) | Trt | Ta=25℃ | - | 30 | 40 | ms | |
| NTSC Ratio | NTSC | CIE1931 | 45 | 60 | - | % | |
| Transmittance | 5.2 | 6.1 | % | ||||
Handling Precautions:
1.The LCD is made of plate glass. Don’t subject the panel to mechanical shock or to excessive force on its surface.
2.Provide a space so that the panel doesn’t come into contact with other components.
|
|
