| Ask Lasest Price | |
| Brand Name : | BOE |
| Model Number : | DV150X0M-N10 |
| Certification : | ROHS |
| Price : | USD49 |
| Payment Terms : | T/T |
| Supply Ability : | 5000pcs |
| Delivery Time : | 5-8 work days |
15 Inch Lcd Screen 1024x768 Full Viewing Angle Lvds Interface 20 Pins
General Description:
Typical features of DV150X0M-N10 are Landscape mode / Portrait mode, white LED backlight, lifetime >50,000 hours, LED driver included, matte surface. Application for industrial, digital signage and other products. Display resolution is 1024 (RGB) x 768 (XGA), aspect ratio is 4:3 (W:H), pixels are arranged in RGB vertical strips.
Features:
Specifications:
| Parameter | Specification | Unit | Remarks |
| Active area | 304. 128(H) × 228.096(V) | mm | |
| Number of pixels | 1024(H) × 768(V) | pixels | |
| Pixel pitch | 0.297(H) × 0.297(V) | mm | |
| Pixel arrangement | Pixels RGB Vertical stripe | ||
| Display colors | 16.7M | colors | 6bits+FRC |
| Display mode | Normally Black | ||
| Dimensional outline | 326.5(H) × 253.5(V) × 9.7(Total) | mm | Detail refer to drawing |
| Weight | 930 | g | |
| Power Consumption | 8.72 | Watt | Typ. |
| Bezel width (L/R/U/D) | 10/10/11.7/11.7 | mm | |
| Surface Treatment | Haze 25%, 3H | ||
| Back-light | E-LED Light bar Type | ||
| LED life | 50000 | ||
| Display Direction | landscape & Portrait |
Absolute Maximum Ratings:
The followings are maximum values which, if exceed, may cause faulty operation or damage to the unit. The operational and non-operational maximum voltage and current values are listed in Table.
| Parameter | Symbol | Min. | Max. | Unit | Remark |
| Power Supply Voltage | VDD | -0.3 | 4 | V | Ta = 25℃ |
| Operating Temperature | TOP | -20 | +70 | ℃ | Note 1 |
Storage Temperature | TSUR | -20 | +70 | ℃ | |
TST | -20 | +70 | ℃ | ||
| Operating Ambient Humidity | Hop | 10 | 90 | %RH | |
| Storage Humidity | Hst | 10 | 90 | %RH |
Note 1 : Wet bulb temperature should be 39℃ max. and no condensation of water.
Electrical Specifications:
| Parameter | Symbol | Values | Unit | Remark | |||
| Min | Typ | Max | |||||
| Power Supply Input Voltage | VDD | 3.0 | 3.3 | 3.6 | V | Note 1 | |
| Power Supply Current | IDD | - | 410 | 740 | mA | ||
| Power Supply Ripple Voltage | VRP | - | - | 300 | mV | ||
| Rush Current | IRUSH | - | 2 | 3 | A | Note 2 | |
LVDS Interface | Differential Input High Threshold Voltage | VLVTH | - | - | +100 | mV | VLVC=1.2V |
Differential Input Low Threshold Voltage | VLVTL | - 100 | - | - | mV | ||
| Common Input Voltage | VLVC | 0.7 | - | 1.6 | V | ||
CMOS Interface | Input High Threshold Voltage | VIH | 0.7VDD | - | VDD | V | |
Input Low Threshold Voltage | VIL | 0 | - | 0.3VDD | V | ||
Power Consumption | PD | 0.8 | 1.3 | W | |||
| PBL | 7.92 | 8.71 | Note 3 | ||||
| Ptotal | 8.72 | 10.1 | |||||
Note 1 : The supply voltage is measured and specified at the interface connector of LCM.The current draw and power consumption specified is for VDD=3.3V,Test Pattern of power supply current.
Note 2 : The duration of rush current is about 2ms and rising time of Power Input is 1ms(min).
Note 3 :Calculated value for reference (Input pins*VPIN × IPIN) excluding inverter loss.
Backlight Electrical Specifications:
| Parameter | Min. | Typ. | Max. | Unit | Remarks | ||
| LED Driver Power Supply Voltage | HVDD | 10.8 | 12 | 12.6 | V | ||
| LED Driver Power Supply Current | IHVDD | 550 | 600 | 700 | mA | ||
EN Control Level | Backlight on | VENH | 3 | 3.3 | 3.6 | V | EN logic high voltage |
| Backlight off | VENL | 0 | 0 | 0.6 | V | EN logic low voltage | |
PWM Control Level | PWM High Level | VPML | 3 | 3.3 | 3.6 | V | |
| PWM Low Level | VPML | 0 | 0 | 0.6 | V | ||
| PWM Control Frequency | F PWM | 0.12 | - | 20 | KHz | Refer to customer comments | |
| Duty Ratio | - | 5 | - | 100 | % | ||
| LED Life-Time | N/A | 50,000 | - | - | Hour | Note4 | |
| LED Light Bar Input Voltage Per Input Pin | VPIN | 32.4 | 36 | 39.6 | V | ||
| LED Light Bar Input Current Per Input Pin | IPIN | - | 55 | - | mA | Note2 | |
| LED Power Consumption | PBL | - | 7.92 | 8.71 | W | Note3 | |
LED bar consists of 48LED packages,4 strings(parallel)*12packages(serial)
Note1: There are one light bar ,and the specified current is input LED chip 100% duty current
Note2: The sense current of each input pin is 55mA
Note3: PBL=4 Input pins*VPIN × IPIN
Note4: The lifetime is determined as the time at which luminance of LED become 50% of the initial brightness or not normal lighting at IPIN=55mA on condition of continuous operating at 25 ± 2℃
Interface Connection:
| Pin No | Symbol | Description | Pin No | Symbol | Description |
| 1 | VDD | Power Supply, 3.3V(typ.) | 11 | RIN2- | -LVDS differential data input 2 |
| 2 | VDD | Power Supply,3.3V(typ.) | 12 | RIN2+ | +LVDS differential data input 2 |
| 3 | VSS | Ground | 13 | VSS | Ground |
| 4 | NC | No Connection | 14 | CLKIN- | -LVDS differential clock input CLK |
| 5 | RIN0- | -LVDS differential data input 0 | 15 | CLKIN+ | +LVDS differential clock input CLK |
| 6 | RIN0+ | +LVDS differential data input 0 | 16 | VSS | Ground |
| 7 | VSS | Ground | 17 | RIN3- | -LVDS differential data input 3 |
| 8 | RIN1- | -LVDS differential data input 1 | 18 | RIN3+ | +LVDS differential data input 3 |
| 9 | RIN1+ | +LVDS differential data input 1 | 19 | VSS | Ground |
| 10 | VSS | Ground | 20 | NC | No Connection |
Optical Specification:
| Parameter | Symbol | Condition | Min | Typ | Max | Unit | Remark | ||
Viewing Angle | Horizontal | Θ3 | CR > 10 | 85 | 89 | Deg. | Note 1 | ||
| Θ9 | 85 | 89 | Deg. | ||||||
| Vertical | Θ12 | 85 | 89 | Deg. | |||||
| Θ6 | 85 | 89 | Deg. | ||||||
| Brightness | Lv | Θ = 0. ILED=55m A | 315 | 350 | nit | ||||
| Uniformity | 9 Points | ΔY9 | 75% | 80% | |||||
| Contrast ratio | CR | Θ = 0. | 700:1 | 1000:1 | - | ||||
Reproduction of color | White | Wx | Θ = 0. (Center) Normal Viewing Angle | TYP. - 0.03 | 0.313 | TYP. + 0.03 | |||
| Wy | 0.329 | ||||||||
| Red | Rx | 0.649 | |||||||
| Ry | 0.338 | ||||||||
| Green | Gx | 0.323 | |||||||
| Gy | 0.627 | ||||||||
| Blue | Bx | 0.155 | |||||||
| By | 0.056 | ||||||||
| Color Gamut | 67 | 72 | - | % | |||||
| Response Time | Tr+Tf | - | 30 | 35 | ms | ||||
| Gamma Scale | 2.0 | 2.2 | 2.4 | ||||||
Note :
1. Viewing angle is the angle at which the contrast ratio is greater than 10. The viewing are determined for the horizontal or 3, 9 o‟clock direction and the vertical or 6, 12 o‟clock direction with respect to the optical axis which is normal to the LCD surface.
Operating Precautions:
1.The electrochemical reaction caused by DC voltage will lead to LCD module degradation, so DC drive should be avoided.
2.The LCD modules use C-MOS drivers, so customers are recommended that any unused input terminal would be connected to Vdd or Vss, do not input any signals before power is turn on, and ground you body, work/assembly area, assembly equipment to protect against static electricity.
|
|
