19 Inch Bar Type Tft Display With 1920x360 Lvds Interface 30 Pins
General Description:
The DV190FBM-NB0 features an LVDS (2 ch, 8-bit) signal interface with a total of 30 pins, a terminal connection, a drive screen voltage of 5.0V (Typ.), and it has a typical vertical refresh rate Fv of 60Hz.
Features:
1.LVDS Interface with 1 pixel / clock
2.Low power consumption
3.6-bit (Hi-FRC) color depth, display 16. 7M colors
4.Incorporated edge type back-light (One Light Bar)
5.High luminance and contrast ratio, low reflection and normal viewing angle
6.DE (Data Enable) only
7.RoHS
8.ES 6.0 compliant
9.Gamma correction
Specifications:
| Parameter | Specification | Unit |
| Active area | 476.64(H) × 89.37(V) | mm |
| Number of pixels | 1920(H) ×360(V) | pixels |
| Pixel pitch | 0.24825(H) ×0.24825(V) | mm |
| Pixel arrangement | RGB Vertical stripe | |
| Display colors | 16.7M | colors |
| Display mode | Normally Black | |
| Dimensional outline | 491.5(H) × 109.5(V) × 8.4(B) | mm |
| Surface treatment | Haze 25% | |
| Bezel width (L/R/U/D) | 6/6/11/6 | mm |
| Weight | 780 ( typ. ) | g |
| Back-light | Up edge side, 1- LED Light bar |
Electrical Specifications:
| Parameter | Min. | Typ. | Max. | Unit | ||
| Power Supply Voltage | VDD | 4.5 | 5.0 | 5.5 | V | |
| Power Supply Current | IDD | - | 500 | 630 | mA | |
| Power Consumption | P D | - | 3 | 4 | W | |
| In-Rush Current | IRUSH | - | 2 | 3 | A | |
| Permissible Input Ripple Voltage | VRF | - | - | 300 | mV | |
| High Level Differential Input Threshold Voltage | VIH | - | - | +100 | mV | |
Low Level Differential Input Threshold Voltage | VIL | - 100 | - | - | mV | |
| Differential input voltage | |VID | 200 | - | 600 | mV | |
| Differential input common mode voltage | Vcm | 1.0 | 1.2 | 1.5 | ||
| LED Channel Voltage | VL | 50.4 | 54 | 55.8 | V | |
| LED Channel Current | IL | - | 32 | 40 | mA | |
| LED Lifetime | 50,000 | - | - | Hrs | ||
Power Consumption | PD | - | 2.5 | 3.15 | W | |
| PBL | - | 6.9 | 8.9 | W | ||
| Ptotal | - | 9.9 | 12.9 | W | ||
Interface Connection:
| Pin No | Symbol | Function |
| 1 | RXO0- | Negative Transmission data of Pixel 0 (ODD) |
| 2 | RXO0+ | Positive Transmission data of Pixel 0 (ODD) |
| 3 | RXO1- | Negative Transmission data of Pixel 1 (ODD) |
| 4 | RXO1+ | Positive Transmission data of Pixel 1 (ODD) |
| 5 | RXO2- | Negative Transmission data of Pixel 2 (ODD) |
| 6 | RXO2+ | Positive Transmission data of Pixel 2 (ODD) |
| 7 | GND | Power Ground |
| 8 | RXOC- | Negative Transmission Clock (ODD) |
| 9 | RXOC+ | Positive Transmission Clock (ODD) |
| 10 | RXO3- | Negative Transmission data of Pixel 3 (ODD) |
| 11 | RXO3+ | PositiveTransmission data of Pixel 3 (ODD) |
| 12 | RXE0- | Negative Transmission data of Pixel 0 (EVEN) |
| 13 | RXE0+ | Positive Transmission data of Pixel 0 (EVEN) |
| 14 | GND | Power Ground |
| 15 | RXE1- | Negative Transmission data of Pixel 1 (EVEN) |
| 16 | RXE1+ | Positive Transmission data of Pixel 1 (EVEN) |
| 17 | GND | Power Ground |
| 18 | RXE2- | Negative Transmission data of Pixel 2 (EVEN) |
| 19 | RXE2+ | Positive Transmission data of Pixel 2 (EVEN) |
| 20 | RXEC- | Negative Transmission Clock (EVEN) |
| 21 | RXEC+ | Positive Transmission Clock (EVEN) |
| 22 | RXE3- | Negative Transmission data of Pixel 3 (EVEN) |
| 23 | RXE3+ | Positive Transmission data of Pixel 3 (EVEN) |
| 24 | GND | Power Ground |
| 25 | CTL | CTL_DVR for LCD manufacturer |
| 26 | CE | CE_DVR for LCD manufacturer |
| 27 | NC | Not connection |
| 28 | VDD1 | Power Supply:+5V |
| 29 | VDD2 | |
| 30 | VDD3 |
Optical Specification:
| Parameter | Symbol | Condition | Min. | Typ. | Max. | Unit | ||
Viewing Angle range | Horizontal | Θ3 | CR > 10 | 85 | 89 | - | Deg. | |
Θ9 | 85 | 89 | - | Deg. | ||||
| Vertical | Θ12 | 85 | 89 | - | Deg. | |||
Θ6 | 85 | 89 | - | Deg. | ||||
| Luminance Contrast ratio | CR | Θ = 0°(Center) Normal Viewing Angle | 900 | 1200 | - | |||
| Luminance of White | Yw | 250 | 300 | - | cd/m2 | |||
White luminance uniformity | ΔY | 75 | 80 | - | % | |||
Reproduction of color | White | Wx | 0.281 | 0.311 | 0.341 | - | ||
| W | 0.296 | 0.326 | 0.356 | |||||
Red | Rx | 0.624 | 0.654 | 0.684 | ||||
| R | 0.299 | 0.329 | 0.359 | |||||
Green | 0.27 | 0.300 | 0.33 | |||||
Gx | ||||||||
Gy | 0.577 | 0.607 | 0.637 | |||||
| Blue | Bx | 0.121 | 0.151 | 0.181 | ||||
| B | 0.045 | 0.075 | 0.105 | |||||
| Color Gamut | - | 72 | - | % | ||||
Response Time | TR | Tr+Tf | - | 30 | 35 | ms | ||
Handling Precautions:
1.Since a module is composed of electronic circuits, it is not strong to electrostatic discharge.Make certain that treatment persons are connected to ground through wrist band etc. And don’t touch interface pin directly. Keep products as far away from static electricity as possible.
2.Avoid the use work clothing made of synthetic fibers. We recommend cotton clothing or other conductivity-treated fibers.
|
|
