28 Inch Bar Type Lcd 1920x360 With Ips Viewing Angle Lvds Interface
General Description:
DV280FBM-NB1 is a color active matrix TFT LCD Module using amorphous silicon TFT's (Thin Film Transistors) as an active switching devices. This Module has a 28inch diagonally measured active area with FHD resolutions (1920 horizontal by 360 vertical pixel array). Each pixel is divided into RED, GREEN, BLUE dots which are arranged in vertical stripe and this module can display 16.7M colors. The TFT-LCD panel used for this Module is adapted for a low reflection and higher color type.
Features:
1.Cutting efficiency 90.5%,panel transmittance 6%.
2.4 shot normal design, High Response Time 8ms.
3.Matrix Vcom design(1/3).
4.Lightweight design,Body 8.9mm ,Depth 16.8mm.
5.Array process :1+4mask, AT :2G3D, Q-CT: 2G3D(S/B detection).
6.RoHS compliant
Specifications:
| Parameter | Specification | Unit |
| Active Area | 699.84(H)*131.22(V) | mm |
| Number Of Pixels | 1920(H)×360(V) | pixels |
| Pixel Pitch | 121.5 × 364.5 | um |
| Pixel Arrangement | Pixels RGB stripe arrangement | |
| Display Colors | 16.7M(8bits) | colors |
| Display Mode | ADS | |
| Brightness | 700 | nit |
| MDL Outline | 732(H)x165(V) | mm |
| MDL Thickness | 16.8 | mm |
| Power Consumption | 24.8 ( Logic :4.2, BLU :20.6 ) | watt |
Absolute Maximum Ratings:
| Parameter | Symbol | Min. | Max. | Unit | Remark |
| Power Supply Voltage | VDD | VSS-0.3 | 13.2 | V | Ta = 25℃ |
| Operating Temperature | TOP | 0 | +50 | ℃ | |
| TSUR | 0 | +60 | ℃ | ||
| Storage Temperature | TST | -20 | +60 | ℃ | |
| Operating Ambient Humidity | Hop | 10 | 80 | %RH | |
| Storage Humidity | Hst | 10 | 80 | %RH |
Electrical Specifications:
| Parameter | Symbol | Values | Unit | |||
| Min | Typ | Max | ||||
| Power Supply Input Voltage | VDD | 10.8 | 12 | 13.2 | V | |
| Power Supply Ripple Voltage | VRP | 500 | mV | |||
| Power Supply Current | IDD | - | 263 | 340 | A | |
| Power Consumption | PDD | 3.156 | 4.2 | W | ||
LVDS Interface | Differential Input High Threshold Voltage | VRTH | +100 | +360 | mV | |
| Differential Input Low Threshold Voltage | VRTL | -360 | - 100 | mV | ||
| Common Input Voltage | VLVC | 1.0 | 1.2 | 1.4 | V | |
CMOS Interface | Input High Threshold Voltage | VIH | 2.7 | - | 3.3 | V |
| Input Low Threshold Voltage | VIL | 0 | - | 0.6 | V | |
Interface Connection:
| Pin No | Symbol | Description | Pin No | Symbol | Description |
| 1 | N.C. | No Connection | 24 | N.C. | No Connection |
| 2 | SDA | SDA | 25 | N.C. | No Connection |
| 3 | SCL | SCL | 26 | GND | Ground |
| 4 | WP | W rite Production | 27 | GND | LVDS Receiver Signal(+) |
| 5 | N.C. | Ground | 28 | CH2_0- | LVDS Channel 2,Signal0- |
| 6 | N.C. | Ground | 29 | CH2_0+ | LVDS Channel 2,Signal0+ |
| 7 | LVDS_SEL | ‘H’=JEIDA , ‘L’or NC= VESA | 30 | CH2_1- | LVDS Channel 2,Signal1- |
| 8 | N.C. | Ground | 31 | CH2_1+ | LVDS Channel 2,Signal1+ |
| 9 | N.C. | No Connection | 32 | CH2_2- | LVDS Channel 2,Signal2- |
| 10 | GND | No Connection | 33 | CH2_2+ | LVDS Channel 2,Signal2+ |
| 11 | GND | Ground | 34 | GND | Ground |
| 12 | CH1_0- | LVDS Channel 1,Signal0- | 35 | CH2_CLK- | LVDS Channel 2,Clock- |
| 13 | CH1_0+ | LVDS Channel 1,Signal0+ | 36 | CH2_CLK+ | LVDS Channel 2, Clock+ |
| 14 | CH1_1- | LVDS Channel 1,Signal1- | 37 | GND | Ground |
| 15 | CH1_1+ | LVDS Channel 1,Signal1+ | 38 | CH2_3- | LVDS Channel 2,Signal3- |
| 16 | CH1_2- | LVDS Channel 1,Signal2- | 39 | CH2_3+ | LVDS Channel 2,Signal3+ |
| 17 | CH1_2+ | LVDS Channel 1,Signal2+ | 40 | N.C. | No Connection |
| 18 | GND | Ground | 41 | N.C. | No Connection |
| 19 | CH1_CLK- | LVDS Channel 1,Clock- | 42 | GND | Ground |
| 20 | CH1_CLK+ | LVDS Channel 1, Clock+ | 43 | GND | Ground |
| 21 | GND | 44 | GND | Ground | |
| 22 | CH1_3- | LVDS Channel 1,Signal3- | 45 | GND | Ground |
| 23 | CH1_3+ | LVDS Channel 1,Signal3+ | 46 | GND | Ground |
| 47 | N.C. | No Connection | 50 | VDD | Power Supply +12.0V |
| 48 | VDD | Power Supply +12.0V | 51 | VDD | Power Supply +12.0V |
| 49 | VDD | Power Supply +12.0V |
Optical Specification:
| Parameter | Symbol | Condition | Min | Typ | Max | Unit | ||
Viewing Angle | Horizontal | Θ3 | CR > 10 | 89 | Deg. | |||
| Θ9 | 89 | Deg. | ||||||
| Vertical | Θ12 | 89 | Deg. | |||||
| Θ6 | 89 | Deg. | ||||||
| Contrast ratio | CR | Θ = 0°(Center) Normal Viewing Angle | 1200:1 | |||||
| Luminance of White | Yw | 700 | nit | |||||
| White luminance uniformity | ΔY | 75 | 80 | % | ||||
| Color Gamut | 72 | % | ||||||
Reproduction of color | White | Wx | 0.275 | |||||
Wy | 0.300 | |||||||
| Red | Rx | 0.652 | ||||||
Ry | 0.331 | |||||||
| Green | Gx | 0.287 | ||||||
Gy | 0.617 | |||||||
| Blue | Bx | 0.147 | ||||||
By | 0.084 | |||||||
| Response Time | G to G | Tg | - | 8 | - | ms | ||
| Gamma Scale | 2.0 | 2.2 | 2.4 | |||||
| Cell Transmittance | 6.0 | % | ||||||
|
|
