21.2 Inch Bar Type Lcd Display 1920x360 Ips Viewing Angle Lvds Interface 30 Pins
General Description:
1.LVDS interface with 2 pixel / clock
2.High-speed response
3.Low color shift image quality
4.8-bit color depth, display 16.7M colors
5.Wide viewing angle
6.DE (Data Enable) only mode
Specifications:
| Item | Content | Unit |
| Active area | 529.416(H)×99.2655(V) | mm |
| Number of pixels | 1920(H)×360(V) | / |
| Pixel pitch | 91.9125(H)×275.7375(V) | / |
| Pixel arrangement | Pixels RGB Vertical stripe | / |
| Backlight Type | 4*20chips white LED | / |
| outline dimension | 543.5*118.5*7.5 | mm |
| Interface Type | LVDS | / |
| LCM Luminance | 600(typ) | nit |
| Display colors | 16.7M | |
| Open Cell Transmittance | 4.8 | % |
| Power Consumption | 3 | TYP |
| Surface Treatment | Haze 25% |
Absolute Maximum Ratings:
| Parameter | Symbol | Min. | Max. | Unit | Remark |
| Power Supply Voltage | VDD | VSS-0. | 13.2 | V | Ta = 25℃ |
| Operating Temperature | TOP | 0 | +50 | ℃ | |
Storage Temperature | TSUR | -20 | +60 | ℃ | |
| TST | -20 | +60 | ℃ | ||
| Operating Ambient | Hop | 10 | 80 | %RH | |
| Storage Humidity | Hst | 10 | 80 | %RH |
Electrical Specifications:
Parameter | Symbol | Values | Unit | |||
| Min | Typ | Max | ||||
| Power Supply Input Voltage | VDD | 10.8 | 12 | 13.2 | Vdc | |
| Power Supply Ripple Voltage | VRP | 300 | mV | |||
| Power Supply Current | IDD | - | 250 | 530 | mA | |
| Power Consumption | PDD | - | 3 | 7 | Watt | |
| Rush current | IRUSH | - | - | 3 | A | |
LVDS Interface | Differential Input High Threshold Voltage | VLVTH | 100 | 300 | mV | |
| Differential Input Low Threshold Voltage | VLVTL | -300 | - 100 | mV | ||
| Common Input Voltage | VLVC | 1 | 1.2 | 1.4 | V | |
CMOS Interface | Input High Threshold Voltage | VIH | 2.7 | - | 3.3 | V |
| Input Low Threshold Voltage | VIL | 0 | - | 0.6 | V | |
Interface Connection:
| Pin No | Symbol | Description |
| 1 | RXO0- | Negative Transmission data of Pixel 0 (ODD) |
| 2 | RXO0+ | Positive Transmission data of Pixel 0 (ODD) |
| 3 | RXO1- | Negative Transmission data of Pixel 1 (ODD) |
| 4 | RXO1+ | Positive Transmission data of Pixel 1 (ODD) |
| 5 | RXO2- | Negative Transmission data of Pixel 2 (ODD) |
| 6 | RXO2+ | Positive Transmission data of Pixel 2 (ODD) |
| 7 | BIST | BIST function |
| 8 | RXOC- | Negative Transmission Cloc k (ODD) |
| 9 | RXOC+ | Positive Transmission Clock(ODD) |
| 10 | RXO3- | Negative Transmission data of Pixel 3 (ODD) |
| 11 | RXO3+ | PositiveTransmission data o f Pixel 3 (ODD) |
| 12 | RXE0- | Negative Transmission data of Pixel 0 (EVEN) |
| 13 | RXE0+ | Positive Transmission data of Pixel 0 (EVEN) |
| 14 | GND | Power Ground |
| 15 | RXE1- | Negative Transmission data of Pixel 1 (EVEN) |
| 16 | RXE1+ | Positive Transmission data of Pixel 1 (EVEN) |
| 17 | GND | Power Ground |
| 18 | RXE2- | Negative Transmission data of Pixel 2 (EVEN) |
| 19 | RXE2+ | Positive Transmission data of Pixel 2 (EVEN) |
| 20 | RXEC- | Negative Transmission Cloc k (EVEN) |
| 21 | RXEC+ | Positive Transmission Clock (EVEN) |
| 22 | RXE3- | Negative Transmission data of Pixel 3 (EVEN) |
| 23 | RXE3+ | Positive Transmission data of Pixel 3 (EVEN) |
| 24 | GND | Power Ground |
| 25 | SCL | CTL_DVR for LCD manufact urer |
| 26 | SDA | CE_DVR for LCD manufactu rer |
| 27 | NC | Not connection |
| 28-30 | VDD | PowerSupply:+12V |
Handling Precautions:
1.Do not connector or disconnect the cable to/from the Module at the “Power On” Condition.
2.When the module is operating, do not lose CLK, ENAB signals. If any one of these signals is lost, the LCD panel would be damaged.
|
|
