21.5 Inch Lcd Panel 1920x1080 Lvds Interface 30 Pins HR215WU1-120
General Description:
HR215WU1-120 type is a-Si TFT-LCD , liquid crystal module, operating temperature is 0 ~ 50 °C, storage temperature is -20 ~ 60 °C, typical features are wide color gamut, surface matte, wide viewing angle, landscape mode, white LED backlight, wide screen, signal terminal inverted.
Features:
1.LVDS Interface with 2 pixel / clock
2.High-speed response
3.6-bit (Hi-FRC) color depth, display 16. 7M colors
4.Incorporated edge type back-light (One Light Bar)
5.High luminance and contrast ratio, low reflection and wide viewing angle
6.DE (Data Enable) only
7.RoHS /TCO 6.0 ,ES6.0 Compliant
Specifications:
| Parameter | Specification | Unit |
| Active area | 476.64(H) × 268. 11 (V) | mm |
| Number of pixels | 1920(H) ×1080(V) | pixels |
| Pixel pitch | 0.24825(H) ×0.24825(V) | mm |
| Pixel arrangement | RGB Vertical stripe | - |
| Display colors | 16.7M | colors |
| Display mode | Normally Black | - |
| Dimensional outline | 495.6(H) × 292.2(V) × 10.7(D) typ. | mm |
| Weight | 1900 (typ.) | g |
| Surface Treatment | Anti-glare, 3H | - |
| Back-light | Lower side 1-LED Light bar Type | - |
Absolute Maximum Ratings:
Parameter | Symbol | Min. | Max. | Unit | Remarks |
| Power Supply Voltage | VDD | -0.5 | 5.5 | V | Ta = 25℃ |
| Logic Supply Voltage | VIN | VSS-0.3 | VDD+0.3 | V | |
| Operating Temperature | TOP | 0 | +50 | C | |
| Storage Temperature | TST | -20 | +60 | C |
Electrical Specifications:
| Parameter | Min. | Typ. | Max. | Unit | Remarks | ||
| Power Supply Voltage | VDD | 4.5 | 5.0 | 5.5 | V | ||
| Power Supply Current | IDD | - | 800 | 1400 | mA | ||
| In-Rush Current | IRUSH | - | - | 3 | A | ||
| Permissible Input Ripple Voltage | VRF | - | - | 200 | mV | VDD = 5.0V | |
High Level Differential Input Threshold Voltage | VIH | - | - | +100 | mV | ||
Low Level Differential InputThreshold Voltage | VIL | - 100 | - | - | mV | ||
| Differential input voltage | VID | 200 | - | 600 | mV | ||
| Differential input common mode voltage | Vcm | 1.0 | 1.2 | 1.5 | VIH=100mV, V =- 100mV | ||
| LED Voltage | VL | 3.05 | 3.2 | 3.4 | V | ||
| LED Channel Voltage | VL | 45.75 | 48 | 51 | V | ||
| LED Channel Current | IL | - | 60 | - | mA | ||
| LED Lifetime | 30,000 | - | - | Hrs | I =60 mA | ||
Power Consumption | PD | - | 4.9 | 6.25 | W | ||
PBL | - | 11.52 | 12.24 | W | IL=60 mA | ||
Ptotal | - | 16.42 | 18.49 | W | |||
Optical Specifications:
VDD = 5.0V, Frame rate = 60Hz, Clock = 78MHz, IBL = 120mA, Ta =25±2℃
| Parameter | Symbol | Condition | Min. | Typ. | Max. | Unit | ||
Viewing Angle range | Horizontal | Θ3 | CR > 10 | - | 89 | - | Deg. | |
Θ9 | - | 89 | - | Deg. | ||||
| Vertical | Θ12 | - | 89 | - | Deg. | |||
Θ6 | - | 89 | - | Deg. | ||||
Viewing Angle range | Horizontal | Θ3 | CR > 5 | - | 89 | - | Deg. | |
Θ9 | - | 89 | - | Deg. | ||||
| Vertical | Θ12 | - | 89 | - | Deg. | |||
Θ6 | - | 89 | - | Deg. | ||||
| Luminance Contrast ratio | CR | Θ = 0° (Center) Normal Viewing Angle | 700 | 1000 | - | |||
| Luminance of White | Yw | 200 | 250 | - | cd/m2 | |||
| White luminance uniformity | ΔY | 75 | 80 | - | % | |||
Reproduction of color | White | Wx | 0.283 | 0.313 | 0.343 | |||
Wy | 0.299 | 0.329 | 0.359 | |||||
| Red | Rx | 0.617 | 0.647 | 0.677 | ||||
Ry | 0.309 | 0.339 | 0.369 | |||||
| Green | Gx | 0.277 | 0.307 | 0.337 | ||||
Gy | 0.603 | 0.633 | 0.663 | |||||
| Blue | Bx | 0.116 | 0.146 | 0.176 | ||||
By | 0.026 | 0.056 | 0.086 | |||||
Response Time | Rising+Fal ling | Tr +Tf | 14 | 21 | ms | |||
| Cross Talk | CT | - | - | 2.0 | % | |||
Interface Connection:
Module Side Connector : UJU IS100-L300-C23 or Equivalent
User Side Connector : JAE FI-X30H or Equivalent
| Pin No | Symbol | Function |
| 1 | RXO0- | Negative Transmission data of Pixel 0 (ODD) |
| 2 | RXO0+ | Positive Transmission data of Pixel 0 (ODD) |
| 3 | RXO1- | Negative Transmission data of Pixel 1 (ODD) |
| 4 | RXO1+ | Positive Transmission data of Pixel 1 (ODD) |
| 5 | RXO2- | Negative Transmission data of Pixel 2 (ODD) |
| 6 | RXO2+ | Positive Transmission data of Pixel 2 (ODD) |
| 7 | BIST | L(GND):Black, H(3.3V):Rotational Pattern |
| 8 | RXOC- | Negative Transmission Clock (ODD) |
| 9 | RXOC+ | Positive Transmission Clock (ODD) |
| 10 | RXO3- | Negative Transmission data of Pixel 3 (ODD) |
| 11 | RXO3+ | PositiveTransmission data of Pixel 3 (ODD) |
| 12 | RXE0- | Negative Transmission data of Pixel 0 (EVEN) |
| 13 | RXE0+ | Positive Transmission data of Pixel 0 (EVEN) |
| 14 | GND | Power Ground |
| 15 | RXE1- | Negative Transmission data of Pixel 1 (EVEN) |
| 16 | RXE1+ | Positive Transmission data of Pixel 1 (EVEN) |
| 17 | GND | Power Ground |
| 18 | RXE2- | Negative Transmission data of Pixel 2 (EVEN) |
| 19 | RXE2+ | Positive Transmission data of Pixel 2 (EVEN) |
| 20 | RXEC- | Negative Transmission Clock (EVEN) |
| 21 | RXEC+ | Positive Transmission Clock (EVEN) |
| 22 | RXE3- | Negative Transmission data of Pixel 3 (EVEN) |
| 23 | RXE3+ | Positive Transmission data of Pixel 3 (EVEN) |
| 24 | GND | Power Ground |
| 25 | NC | Not connection, this pin should be open |
| 26 | NC | Not connection, this pin should be open |
| 27 | NC | Not connection |
| 28 | VDD1 | Power Supply:+5V |
| 29 | VDD2 | |
| 30 | VDD3 |
Handling Precautions:
1.Since CMOS LSI is used in this module, take care of static electricity and injure the human earth when handling. Observe all other precautionary requirements in handling components.
2.This module has its circuitry PCBs on the side and should be handled carefully in order not to be stressed.
|
|
