21.5 Inch Ips Tft Screen 1920x1080 With Lvds Interface 30 Pins 250 Nits
General Description:
The M215HCA-L3B has an operating temperature of 0 ~ 50°C, a storage temperature of -20 ~ 60°C, and a vibration resistance of 1.5G (14.7 m/s²). This model is recommended for computer monitors based on its 3-sided bezel-less, white LED backlight, terminal flip-flop, and matte surface features.
Specifications:
| Item | Specification | Unit |
| Screen Size | 21.5” real diagonal | |
| Driver Element | a-si TFT active matrix | - |
| Pixel Number | 1920 x R.G.B. x 1080 | pixel |
| Pixel Pitch | 0.24795 (H) x 0.24795 (V) | mm |
| Pixel Arrangement | RGB vertical stripe | - |
| Display Colors | 16.7M(8bit) | color |
| Transmissive Mode | Normally Black | - |
| Surface Treatment | AG type, 3H hard coating, Haze 25 | - |
| Luminance, White | 250 | Cd/m2 |
| Color Gamut | 72% of NTSC(Typ.) | - |
| Display Orientation | Signal input with “ INX” | |
| RoHS,Halogen Free &TCO 6.0 | RoHS, Halogen Free TCO 6.0 compliance | |
| Power Consumption | Total 15.93W (Max.) @ cell 4.05W (Max.), BL 11.88W (Max.) | |
Absolute Maximum Ratings:
| Item | Symbol | Value | Unit | |
| Min. | Max. | |||
| Storage Temperature | TST | -20 | 60 | ºC |
| Operating Ambient Temperature | TOP | 0 | 50 | ºC |
Electrical Specifications:
| Parameter | Symbol | Value | Unit | ||||
| Min. | Typ . | Max . | |||||
| Power Supply Voltage | Vcc | 4.5 | 5.0 | 5.5 | V | ||
| Ripple Voltage | VRP | - | - | 300 | mV | ||
| Rush Current | IRUSH | - | - | 3 | A | ||
Power Supply Current | White | - - - | - | 550 | 640 | mA | |
| Black | - | 530 | 620 | mA | |||
| Vertical Stripe | - | 700 | 810 | mA | |||
| Power Consumption | PLCD | - | 3.5 | 4.05 | Watt | ||
LVDS interface | Differential Input Voltage | VID | 100 | - | 600 | mV | |
| Common Input Voltage | VCM | 1.0 | 1.2 | 1.4 | V | ||
| Differential Input High Threshold Voltage | VTH | - | - | +100 | mV | ||
| Differential Input Low Threshold Voltage | VTL | - 100 | - | - | mV | ||
Interface Connection:
| Pin | Name | Description |
| 1 | RXO0- | Negative LVDS differential data input. Channel O0 (odd) |
| 2 | RXO0+ | Positive LVDS differential data input. Channel O0 (odd) |
| 3 | RXO1- | Negative LVDS differential data input. Channel O1 (odd) |
| 4 | RXO1+ | Positive LVDS differential data input. Channel O1 (odd) |
| 5 | RXO2- | Negative LVDS differential data input. Channel O2 (odd) |
| 6 | RXO2+ | Positive LVDS differential data input. Channel O2 (odd) |
| 7 | GND | Ground |
| 8 | RXOC- | Negative LVDS differential clock input. (odd) |
| 9 | RXOC+ | Positive LVDS differential clock input. (odd) |
| 10 | RXO3- | Negative LVDS differential data input. Channel O3(odd) |
| 11 | RXO3+ | Positive LVDS differential data input. Channel O3 (odd) |
| 12 | RXE0- | Negative LVDS differential data input. Channel E0 (even) |
| 13 | RXE0+ | Positive LVDS differential data input. Channel E0 (even) |
| 14 | GND | Ground |
| 15 | RXE1- | Negative LVDS differential data input. Channel E1 (even) |
| 16 | RXE1+ | Positive LVDS differential data input. Channel E1 (even) |
| 17 | GND | Ground |
| 18 | RXE2- | Negative LVDS differential data input. Channel E2 (even) |
| 19 | RXE2+ | Positive LVDS differential data input. Channel E2 (even) |
| 20 | RXEC- | Negative LVDS differential clock input. (even) |
| 21 | RXEC+ | Positive LVDS differential clock input. (even) |
| 22 | RXE3- | Negative LVDS differential data input. Channel E3 (even) |
| 23 | RXE3+ | Positive LVDS differential data input. Channel E3 (even) |
| 24 | GND | Ground |
| 25 | NC | For LCD internal use only, Do not connect |
| 26 | NC | For LCD internal use only, Do not connect |
| 27 | NC | For LCD internal use only, Do not connect |
| 28 | Vcc | +5.0V power supply |
| 29 | Vcc | +5.0V power supply |
| 30 | Vcc | +5.0V power supply |
Handling Precautions:
1.Do not leave the module in high temperature, and high humidity for a long time. It is highly recommended to store the module with temperature from 0C to 35C and relative humidity of less than 90%.
2.Do not store the TFT – LCD module in direct sunlight.
|
|
